Medium Voltage Covered Conductor (MVCC)
Conductor Material
All Aluminum Alloy or ACS with Aluminum Alloy
Stranding
Upto 37 Strands
Inner Layer
Extruded Semi Conducting Compound (Black Colour)
Middle Layer
Extruded XLPE (Natural Colour)
Outer Layer
Extruded XLPE with UV Resistive and Anti-Tracking Properties (Black Colour)
Standard
EN 50397-1/2021 (with latest amendments)
03 / 02
MVCC is a specially designed insulated overhead conductor used for medium voltage power distribution, typically in the range of 11 kV to 33 kV. It is an ideal solution for areas prone to high vegetation, wildlife interference, and challenging weather conditions. Unlike bare conductors, MVCC has multiple insulation layers that offer enhanced safety, reduced outages, and lower maintenance. It allows for closer conductor spacing, minimizes the risk of short circuits due to external contact, and ensures uninterrupted power supply even in harsh environments. MVCC is widely used in rural, forested, and coastal areas, as well as in urban zones where reliability and safety are critical.
Construction
The Medium Voltage Covered Conductor (MVCC) is made of All Aluminum Alloy (AAAC) or ACS with Aluminum Alloy, stranded in up to 37 strands for strength and flexibility. The conductor is longitudinally water-tight, preventing moisture ingress and ensuring long-term reliability. It is insulated with three layers: an inner semi-conducting compound (black) for stress control, a middle XLPE layer (natural) for primary insulation, and an outer XLPE sheath (black) with UV resistance and anti-tracking properties for protection against environmental factors. This construction offers enhanced safety and durability in overhead distribution systems.
Applications
Overhead medium-voltage distribution lines (11kV to 33kV)
Forested or wildlife-sensitive corridors
Urban and semi-urban zones with minimal clearance
Long spans with limited support structures
Areas requiring enhanced electrical safety and reduced outage risk
Key Performance Features
Triple-layered insulation system for maximum protection
Excellent electrical and thermal performance
Highly UV, moisture, and corrosion resistant
Reduces power theft, tree faults, and phase-to-ground contact issues
Compact and easy to string
Long service life under extreme environmental conditions
Certification
Compliant with IEC 60502-1 / IS 7098 Part II
ISO 9001:2015 Certified Manufacturing
Type-tested at NABL-accredited laboratories
Quality controlled for dielectric strength, insulation resistance, and dimensional accuracy
